Subchondral bone cyst
Findings are Pro only. Every normal study is free; Pro opens each finding beside its normal.
See ProWhat to look for
- Round lucency in the subchondral bone of the distal proximal phalanx (arrowhead)
- A sclerotic (bright) rim around it
- Check the same spot on the other limbs: cyst-like lesions are often bilateral
Against the normal
Read every bone's outline and density, then every joint: the space, the margins and the bone under the cartilage. Compare with the other limb, and always take at least two views at right angles.
Source: Wendling E. M. et al., Front Vet Sci 2026. CC BY 4.0. For learning: not a diagnostic service.
